9KVA-16KVA Open Type Air Cooled Diesel Generator

Frequency

50/60HZ

50/60HZ

Rated Power

12.5KVA/9KW

15KVA/11KW

Max Power

13.5KVA/10KW

16KVA/12KW

Voltage

230/400V

230/400V

Current

43.5/19.5A

52.2/23.1A

Plugs

32A & 63A

32A & 63A

Display

LED 3 /LED 6

LED 3 /LED 6

Fuel Tank Capacity

22L

22L

Running Time @75% Load

7.5H

6.5H

Sound Level

79 dBA

84 dBA

DC Output

12V/8.3A

12V/8.3A

Battery

12V 36Ah

12V 36Ah

Engine

D900E

D1000E

Engine Type

Diesel

Diesel

Power

18.6Hp

20Hp

Start

Electric

Electric

Displacement

912cc

967cc

Oil Capacity

3L

3.8L

Alternator

AL10-T

AL12-T

Power

10KW

12KW

Power factor

1/0.8

1/0.8

Voltage Regulation

Brush AVR

Brush AVR

Dimension & Weight

Net Weight

177Kg

210Kg

Gross Weight

195Kg

235Kg

Machine Dimension

1050 x 660 x 720 mm

1050 x 660 x 720 mm

Packing Dimension

1115 x 735 x 850 mm

1165 x 705 x 905 mm

Loading Container

FCL 20 FT/40HQ

30/96

30/60
