Mobile Diesel Generator Power Station supplier

Type: KGPS21S
Engine Model: Engine model
Alternator brand: Leroy Somer
Engine brand: Perkins
Online consultation
Consultation hotline:+65 9825 7795

Product introduction

Product Description:

The rotation of the diesel engine crankshaft drives the generator to generate electricity. The generator includes a DC generator and an AC generator. DC generator is mainly composed of generator shell, magnetic pole core, magnetic field coil, armature and carbon brush. Working power generation principle: when the diesel engine drives the generator armature to rotate, the armature coil cuts the magnetic field lines in the magnetic field due to the residual magnetism of the generator's magnetic pole core. According to the principle of electromagnetic induction, the current is generated by magnetic induction and the current is output through the carbon brush.

KGPS21S Telecommunication Generator

ServicePRP(1)ESP(2)
Genset power (KVA)2123
Genset power (KW)16.818
Voltage (V)200
Frequency60Hz
Engine speed1800R.P.M
Power factor(cos phi)0.8
PhaseThree Phase
Noise Level65dbm @7m
Amps23.5A


Kingway generator sets are compliant with ISO 9001 and CE standard, which include the following directives:

2006/42/EC Machinery safety.

2006/95/EC Low voltage

EN 60204-1: 2006+A1: 2009, EN ISO 12100: 2010, EN ISO 13849-1:2008, EN 12601: 2010

(1) PRP (Prime Power)

Prime power Continuous running at variable load for unlimited periods with 10% overload available for 1 hour in any 12 hour period.

In accordance with ISO 8528, ISO 3046.

(2) ESP (Standby Power)

Standby power: Continuous running at variable load for duration of an emergency. No overload is permitted on these ratings. In accordance with ISO 3046.


Genset ModelKGPS21S
Engine brandPerkins
Engine model404D-22G
Speed control typeElectronic
Alternator brandLeroy Somer
ExcitationBrushless Self Exciting
Alternator ModelTAL-A40-G
Control ModuleAMF20+ GSM
Frequency60HZ
