100KW-2000KW Automatic Load Bank

Model : KLB-100
Type of load: Resistive PF=1.0
Testing capacity: 0-100kw
Duty: Continuous
Tags: 3 phase Load Bank
Online consultation
Consultation hotline:+65 9825 7795

Product introduction

Technical Specifications

ModelTesting capacityType of loadDutyCooling systemPhaseRated testing voltageRated FrequencyDimensions (L*W*H)Weight (kg)
KLB-1000-100kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz960x1060x1400350
KLB-2000-200kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz1560x1310x1650500
KLB-3000-300kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz1690x1440x17501083
KLB-4000-400kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz1900x1600x19001200
KLB-5000-500kwResistiv PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz1900x1600x19001400
KLB-6000-600kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz2100x1730x20001550
KLB-7000-700kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz2100x1730x20001650
KLB-8000-800kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz2400x2030x21001750
KLB-10000-1000kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz2400x2030x21002150
KLB-20000-2000kwResistive PF=1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz20ft container6000


It used to the voltage of 220-690V or 127/220v,220/380v,230/400v,240/415v,277/480v

Kingway Load bank is a simulating load test equipment used for generators,UPS,battery banks etc power systems testing.

1.Generator system R&D and routine test(inspection).

2.Standby generator routine maintenance load test.

3.Acceptance test for power supply project.

4.UPS products R&D,routine test and maintence.

5.Load profile optimization test for electric power supply system.


Technical Specifications

ModelTesting capacityType of loadDutyCooling
system		PhaseRated testing voltageRated FrequencyDimensions (L*W*H)Weight (kg)
KLB-1250-125kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz960x1060x1400770
KLB-2500-250 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz1560x1310x16501100
KLB-3750-375 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz1690x1440x17501700
KLB-5000-500 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz1900x1600x19002060
KLB-6250-625 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz1900x1600x19003200
KLB-7500-750 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz2100x1730x20003600
KLB-8750-875 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz2100x1730x20004000
KLB-10000-1000 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz2400x2030x21004730
KLB-12500-1250 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz2400x2030x21005000
KLB-25000-2500 kvaInductive &Resistive PF=0.8-1.0ContinuousIndustrial grade axial fanAvailable at both single and three phase110-480 VAC50/60 Hz20ft container132

It used to the voltage of 220-690V or 127/220v,220/380v,230/400v,240/415v,277/480v
